Caddx MB05-2 1/2.7 CMOS 800TVL Sensor Board Camera Module 1080P 60fps WDR for Turtle V2 WN-Sensor

RM0.00

Out of stock

SKU: WN-Sensor Category:

Caddx MB05-2 1/2.7 CMOS 800TVL Sensor Board Camera Module 1080P 60fps WDR for Turtle V2 WN-Sensor

Specification
Image sensor: 1/2.7″ CMOS sensor
Horizontal: 800TVL
TV system: NTSC/PAL,changeable
Video Resolution: 1080P@60fps / 1080P@30fps / 720@60fps
Power Input: DC 4.5-20V
Mini Illumination: 0.01lux
Image Resolution: 2 Megapixels
Working Current: 380mA@5V/160mA@12V (low consumption)
Electronic Shutter : PAL : 1/50-100,000 NTSC : 1/60-100,100
S/N Ratio: >60dB (AGC OFF)

Package Included
1 x Camera Sensor Board

Dimensions 10 × 10 × 10 cm
