GEPRC CineLog25 Analog w/Runcam Nano 2 600mW VTX 109mm 2.5inch 4S CineWhoop GEP25AN

GEPRC CineLog25 Analog w/Runcam Nano 2 600mW VTX 109mm 2.5inch 4S CineWhoop GEP25AN

Feature:

1.New camera damping system

The New camera damping system basically eliminates the video’s jelly and FPV camera’s vibration in terms of designing, The damping construction can be adjusted the harder or softer to suit the Flight State. There are Three, Four and Five damping rings can be used to provide sufficient stability in vibration and noise.

2.Brand-new exclusive pusher frame

The CineLog Whoop Quadcopter adopts a brand-new stunning pusher frame design, Including ultra-light carbon plate and new material, strength increases by 20%, efficiency increased by 15%

3.Low noise optimization

Cinelog Whoop Quadcopter Increases the Air Inlet volume and it with the EVA foam cushioning,Reduce the Airflow Resistance in order to create extremely low flight noise and greater reduction of noise from external vibrations

4.Long range flight

High efficiency power matching, The GR1404 4500kv(Upgraded Version) power output scheme and Brilliant Tune have further Improved the flight time

5.Low center of gravity design

The CADDX VISTA was placed at the bottom, Optimized Design for the Air Inlet Structure. It’s a point of the greatest importance is a low center of gravity “pusher-style” inverted frame, increased efficiency at least 15%

6.Perfectly Compatible with most of mainstream cameras

Compatible with SMO 4K, Gopro6 lite and Gopro8 Lite (coming soon),etc…

7.Adjustable lens angle

The flight angle of 0-40 degrees can be adjusted according to the flight requirements, The camera’s angle can be adjusted to meet your variety of Shooting needs

8.With EVA foam cushioning

Integrated EVA design, the overall shape look more coordinated, better strength.

9.Optimized bottom design

The bottom part increases the strength of landing and perfectly protects all electronic equipment

10.Camera power line output

With its own power cable output to the camera (Gopro6 & Gopro8),It has its own Video Recording Wire,The camera can be turned off or on directly Via Remote controller

Specifications：
Brand: GEPRC
Frame: GEP-CL25
Wheelbase: 109mm

Flight Controller: F411-35A AIO
MCU: STM32F411
Gyro: 6-Axis

OSD: BetaFlight OSD w/ AT7456E chip
ESC: BLheli_S 20A

VTX: 5.8G 600mW VTX
Camera: Runcam Nano2
Props: GEMFAN D63-3
Motors: GR1404 4500kv(Upgraded Version)
Antenna: GEPRC Momoda 5.8g RHCP
CineLog25 Analog Weight: 128g（Without battery）

Battery: Recommended (NOT Included)
4S 450-750mAh OR
GEPRC 4S 660mAh 90/180C HV 3.8V/4.35V LiPo Battery

Include:
1x CineLog25 Analog
4x D63-3 Props(Pairs)
1x GOPRO Lite 3D TPU Seat
2x EVA Pad
2x Battery non-slip mat
2x Battery strap
1x screwdriver

*Gopro Camera NOT included
