Happymodel SE0702 23000/26000KV 1S 1.0mm Shalf Brushless Motor for Mobula6 ELRS, Mobeetle6 65/75mm FPV Whoop SE0702-2326

RM32.50

Happymodel SE0702 23000/26000KV 1S 1.0mm Shalf Brushless Motor for Mobula6 ELRS, Mobeetle6 65/75mm FPV Whoop SE0702-2326

Features:
The lightest brushless motors all over the world , the weight is only 1.46gram.
You can build an extreme weight tiny whoop with this amazing motors.

Introduction:
The SE0702 brushless motor is the latest product of the Happymodel SE series. The weight of this brushless motor is only 1.46 grams. It should be the lightest brushless motor in the world so far. This motor inherits the consistent style of high quality and cost-effective motors of this series. , Use tile magnets, high-precision CNC shell, high efficiency, good dynamic balance, and use an integrated rotor, more durable, very suitable for assembly of extremely light 65mm or 75mm 1S power Tiny whoop.Great thanks to “Angry Don FPV” for the great job on this light weight 0702 motor.

Description:
Brand: Happymodel
Mode: SE0702
Item Name: 0702 23000KV / 26000KV 1S Brushless Motor
Quantity: 1 PC
Configu-ration: 9N12P
Stator Diamter: 7mm
Stator Length: 2mm
Shaft Diameter: Φ1mm
Motor Dimension(Dia.*Len): Φ9.5mm*14mm
Weight(g): 1.46g
No.of Cells(Lipo): 1S only
Terminal: JST 1.25mm Crazybee series flight control in-line
Outgoing wire length: 35mm (including terminal)

Package Included (Optional) :

1x SE0702 23000KV / 26000KV brushless motor CW

OR

1x SE0702 23000KV /26000KV brushless motor CCW

Weight 0.03 kg
Dimensions 3 × 3 × 3 cm
KV

23000KV-Mobeetle6, 26000KV-Mobula6

Option

CW, CCW
