iFlight Chimera7 PRO V2 6S HD With DJI 03 Air Unit Camera Chimera7 Pro-V2
Description
The KING of Long Range FPV! Another breakthrough in FPV visuals from DJI with our upgraded frame and electronics. A super-efficient iFlight 7.5inch Long-Range bird that can go where you couldn't go before and can carry bigger batteries to get the flight time to surf the swiss alps if you want! A super stiff frame for minimum resonance and XING2 2809 motors for maximum 7.5inch prop control. Fly big batteries top-mounted, or even bigger batteries bottom-mounted, 6cells recommended or 5cells for slow cruising. But whatever style you fly, a Lipo or Lion pack will just do the job. Recommended 5S 3.000mAh above (slow cruising) or our new 6S 3300mAh battery.
Highlights
Smooth and Powerful XING2 Motors
Latest Chimera7 Pro Frame for Maximum Protection
DJI O3 HD Air Unit Low-Latency Digital Transmission
Up to 10 km video transmission range, enjoy a crisp and smooth real-time view in your goggles, even in environments with interference. (Source DJI)
4K Stabilized Video with 155° Ultra-Wide Angle
Secured Battery Plug with Anti-Spark Filter
GPS Pre-Installed for More Safety at A Distance
Specifications
Product Name: Chimera7 Pro V2 6S HD
FC: BLITZ F722 Flight Controller
ESC: BLITZ E55 4-IN-1 2-6S 55A ESC
Video Transmission: DJI O3 Air Unit
Frame: 327mm wheelbase
Motor: XING2 2809 motors
Prop: 7.5X3.7X3 propellers
Weight: 695g
Model: Chimera7 Pro
Takeoff Weight: Approx. 750g
Dimensions (L×W×H)：270x199x34mm
Max Ascent Speed: 6 m/s (Normal Mode, Sport Mode)
Max Descent Speed: 6 m/s (Normal Mode, Sport Mode)
Max Speed: 27 m/s (Manual Mode)
Maximum Takeoff Altitude: 7000 m
Max Hover Time: Approx. 30 mins
Max Flight Distance: 18 km
Max Wind Speed Resistance: 130 Km/H (Level 5)
Operating Temperature Range: -10° to 40° C (14° to 104° F)
Transmission Power (EIRP): FCC: < 33 dBm / CE: < 14 dBm / SRRC: < 30 dBm
Antennas: Dual Antennas
GNSS: GPS + Galileo
Video Transmission
Product Name: DJI O3 Air Unit
Weight: Approx. 290 grams（headband included）
Dimensions (L×W×H): L167 * W1039 * H 813mm
Screen Size (single screen): 0.49-inch
Resolution (single screen): 1920×1080
Refresh Rate: Up to 100 Hz
Interpupillary Distance Range: 56-72 mm
Diopter Adjustment Range: -8.0 D to +2.0 D
FOV (single screen): 51°
Communication Frequency: 2.400-2.4835 GHz；5.725-5.850 GHz
Transmission Power (EIRP):
2.4 GHz: < 30 dBm (FCC), < 20 dBm (CE/SRRC/KC)
5.8 GHz [4]: < 30 dBm (FCC), < 23 dBm (SRRC), < 14 dBm (CE/KC)
Max Video Transmission Bitrate : 50 Mbps
Operating Temperature Range: 0° to 40° C (32° to 104° F)
Power Input: 7-9 V (1.5 A)
Additional Suggested Parts (Not Included)
DJI HD FPV Goggles
GoPro Mount
iFlight FULLSEND LR INR21700-40T 6S1P 4000mAh 22.2V Li-Ion Battery – XT60H
iFlight FULLSEND 6S 3300mAh 95c Lipo Battery – XT60H
Packing List
1 x Chimera7 Pro V2 6S HD
2 x Battery pad
4 x 7.5 inch Prop(Pairs)
2 x Battery strap
1 x Screw bag
